Shenzhen Risingstar Outdoor High Light LCD Co., Lt
Embedded open frame Lcd Display product feature
27"-65" TFT LCD Panel
1920*1080 or 3840*2160 resolution
outdoor used ,the brightness from 500nits to 5000 nits optional
Capacitive touch panel, covered with 2mm tempered glass for vandal proof (IR touch optional)
VGA HDMI DVI USB interface
High performance mainboard, 7x24 continuous operation
Support 12-24V wide voltage
Ultra-thin front bezel 3mm, ideal for embedded mounting
Front panel IP55 waterproof
| Product specification | |
| LCD panel | |
| Panel size | 27"-65" |
| Resolution | 1920*1080 or 3840*2160 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits (can be customized) |
| Contrast ratio | 1300:1 |
| Touch panel | |
| Touchscreen Type | Capacitive Touch (10 points ) |
| Surface Hardness | 7H |
| Luminousness | 90% |
| Touch Interface | USB (RS232 optional) |
| Touch response time | 2ms |
| Working Life | >50 million times |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows ,HDMI, Android, ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12-24V |
| Power consumption | ≤35W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Black, Silver or customized |
| VESA mounting | 75x75mm/100x100mm |
| IP grade | Front panel IP55 waterproof |
| Operating Environment | |
| Temperature Range | operating: -10 to 50°C, storage: -20 to 80°C |
| Relative humidity | operating: -5% to 95%, storage: -5% to 95% |
| Packing Details | |
| Gross weight | about 4kg |
| Accessories | Power adapter, VGA cable, USB touch cable, embedded screws |
| Other | |
| Mounting | embedded mounting screws |
| Wall mounting brackets (optional) | |
| Desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, RoHS |
