21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module
21.5 Inch 1000 Nits High Brightness LCD Module

21.5 Inch 1000 Nits High Brightness LCD Module

Min. Order:1 Piece/Pieces

Product Description
Supply Ability & Additional Information

Productivity1000K

Place of OriginSHENZHEN

CertificateCE/ROSH/UL/ISO9001

Packaging & Delivery
Selling Units:
Piece/Pieces
Product Introduction:
21.5-Inch High Brightness LCD Panel Specifications
Panel Size21.5 inches
Panel Typea-Si TFT-LCD, LCD Module
Resolution1920 (RGB) × 1080, FHD, 102 PPI
Pixel LayoutRGB Vertical Stripe
Display Area (W × H)476.064 × 267.786 mm
Visible Area479.8 × 271.2 mm
Surface TreatmentMatte, Hard Coating (3H)
Brightness1000 to 5000 nits
Contrast Ratio1000:1 (Typical) [Transmissive]
Viewing Angle (L/R/U/D)89° / 89° / 89° / 89° (CR≥10)
Best Viewing DirectionAll View
Optical ModeADS, Normally Black, Transmissive
Response Time14 ms (Typical, G to G)
Color Depth16.7M Colors, 73% NTSC
Backlight Type24S3P WLED, 30,000 hours, Driverless
Panel Weight1.97 kg (Typical)
Recommended ApplicationsIndustrial, Digital Signage
Refresh Rate60Hz (Optional MEMC: 120Hz/240Hz)
Touch FunctionNone
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Supply Voltage5.0V (Typical)
Operating Temperature0 ~ 50°C
Storage Temperature-20 ~ 60°C
