RisingStar 15 inch High Brightness LCD Screen
RisingStar 15 inch High Brightness LCD Screen
RisingStar 15 inch High Brightness LCD Screen
RisingStar 15 inch High Brightness LCD Screen
RisingStar 15 inch High Brightness LCD Screen

RisingStar 15 inch High Brightness LCD Screen

Min. Order:1 Piece/Pieces

Product Description
Packaging & Delivery
Selling Units:
Piece/Pieces
Product Introduction:
Product Introduction

       RisingStar 15inch High Brightness Lcd Screen,The resolution 1024*768.This is square LCD screen.The high brightness can be achieve 1300 nits.

       15 inch high brightness lcd screen usually used in indoor display and semi-outdoor display terminal equipment, more embedded installation, RisingStar 15inch high brightness lcd screen adopts the RisingStar original module, by changing the light bar to achieve indoor high brightness conversion, can be used for semi-outdoor ATM and other terminal equipment. This model can add Touch Screen, 10 point capacitive touch.

15 inch lcd

high brightness screen

lcd screen

15 inch lcd screen

Items Specification Unit Note
Active Screen Size 15 inches
Display Area 304.128*228.096 mm
Outline Dimension 326.5*253.5*6.3 mm
Driver Element a-Si TFT active matrix

Display Colors 16.7M colors
Color Gamut 72 %
Number of Pixels 1024*768 Pixel
Pixel Arrangement RGB vertical stripe


Pixel Pitch 0.21*0.63 mm
Display Mode Normally Black

Surface Treatment Haze 2%,3H


Brightness 1000 nits
Power 25 W
Zoom 4:3

Working temperature 0--60

Weight 1.5 kg
Backlit life 50000 hr
