Shenzhen Risingstar Outdoor High Light LCD Co., Lt
Brand: RisingLCD
Productivity: 100K
Place of Origin: SHENZHEN
Certificate: CE/ROSH/CE/ISO9001
700nits 23.6" panel IPS LVDS 2K high brightness replacement tv screen tft LCD Panel 23.6
| Item | 23.6'' High Brightness Lcd panel |
| Model | RS236ENT-N07 |
| Screen Size | 23.6 inches |
| Display Area | 476.64*268.11mm |
| Outline Dimenssion | 503.5*295.09*16.3mm |
| Panel Type | High brightness LCD with WLED |
| Configuration | RGB Vertical Stripe |
| Resolution | 1920*1080pixel |
| Brightness | 700nits |
| Aspect Ratio | 16:9 |
| Constrast Ratio | 3000:1 (Typ.) (TM) |
| Response Time | 20/5ms (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥20 |
| Driver Elements | a-Si TFT-LCD |
| Surface Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Display Color | 16.7M 72% (CIE1931) |
| Display Mode | MVA, Normally Black, Transmissive |
| Interface Type | 30 pins LVDS (2 ch, 8-bit) , Connector |
| Input Voltage | DC12V |
| Power | 36.2W |
| Weight | 1.9kg |
| Backlit Lifetime | 50000hrs |
| Operating Temp. | 0°- 60°C |
| Storage Temp. | -20°- 60°C |
Hot Tags: 700nits 23.6inch tft lcd panel, China, factory, cheap, price, customized, quotation, window facing LCD, sunlight panel, Semi Outdoor Display Screen, lcd board, High Definition Lcd Board, 65inch Outdoor Lcd, 65 inches display screen, LCD panel, Lcd Module, High Brightness Display.
