10.3" RisingStar LA103WF4-SL03 TFT LCD Module

Min. Order:1 Piece/Pieces

Product Description
Product Attributes

Model No.LA103WF4-SL03

Packaging & Delivery
Selling Units:
Piece/Pieces
Product Introduction:
Product Introduction

10.3 inch RisingStar Display LA103WF4-SL03 high brightness 900nits TFT LCD Panel sunlight visible.

Outdoor highlight LCD screen is generally used in outdoor billboards, outdoor charging piles and electronic bus stops and other places. The highlight LCD screen is to increase the visibility of the LCD screen under strong light by changing the brightness of the backlight. It has the following characteristics:

1. High brightness

Highlight screen is the first high brightness, parameters are generally more than 700CD /m², visible in strong light

2, high contrast

The contrast requirement of highlight screen is also relatively high, generally more than 1000:1, and some special environments can reach 10000:1

3, good reliability performance

The highlight LCD screen can support 7*24 hours continuous uninterrupted work, ordinary LCD screen is unable to do continuous work day and night

4, long service life

Relative to the general LCD screen, the service life of outdoor highlight screen is longer




brand RisingStar Display (RisingStar Display) Model name LA103WF4-SL03
size 10.3" Screen type a-Si TFT-LCD,Lcd Module
resolution 1920(RGB)×720, 200PPI Pixel configuration RGB vertical bar
Display size 243.648(W)×91.368(H) mm Surface treatment Anti-fingerprint (AF), Hard coating (3H), anti-reflection treatment
Brightness(cd/m²) 900 cd/m² (Typ.) contrast 1100:1 (Typ.)
Viewing Angle 89/89/89/89 (Min.)(CR≥10)  Apply to Outdoor highlight, car display
Signal system LVDS (2 ch, 8-bit) , 60 pins , terminal Appearance of size 262.28×113.19×13.09(H×V×D) mm
Maximum rated Storage temperature: -40 ~ 95 °C  Working temperature: -30 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²)
