Product Attributes

Brand: RisingSTAR

Supply Ability & Additional Information

Productivity: 5500K

Place of Origin: SHEN ZHEN

Certificate: CE/ROSH/UL/ISO9001

Packaging & Delivery

Selling Units:

Piece/Pieces

Product Introduction：

Are you looking for a high-performance Lcd Module for your latest project? Let me introduce to you our proud 21.5-inch 800 nits High Brightness Lcd module display. This monitor stands out with its astonishing 800 nits brightness, ensuring clear and visible images even in complex and variable lighting environments, without any pressure.

Whether your project focuses on innovation in commercial displays, strives to create new heights in Digital Signage solutions, or adds a touch of color to the high-end consumer market, this 21.5-inch 800 nits LCD module display will be your top choice. With outstanding brightness performance, vivid color display, and stable and reliable performance, it is sure to inject new vitality into your project and help you climb new heights of success. Choose it to make your project visually more eye-catching and achieve unprecedented breakthroughs.

brand	BOE	Model name	UV215FHM-N10
size	21.5 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1080 FHD 102PPI	Pixel configuration	RGB vertical bar
Display Area	476.64×268.11(H×V)mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Visual size	/	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	500~1000cd/m²(Typ.)or customized	Outline dimension	495.6×292.2×11.2mm(H×V×D)
Viewing Angle	89/89/89/89(Typ.)(CR≥10)	Signal interface	30 pins LVDS (2 ch, 8-bit),erminal
work environment	Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C

21.5-inch all-metal structure high-brightness LCD screen features：

1.Using Risingstar's unique aluminum profile structure, it can match the LCD panels of various manufacturers.

2.All metal structure, good heat dissipation.

3.Direct type structure, equipped with LED backlight Uniform brightness, low power consumption.

4.The automatic dimming system can adjust the brightness of the bright LCD screen according to the ambient light, saving energy and electricity.
