Panel Brand | RISINGSTAR | Panel Model | RS150ENT-NE10 |
Panel Size | 15" | Panel Type | a-Si TFT-LCD , LCM |
Resolution | 1024(RGB)×768 [XGA] 85PPI | Pixel Format | RGB Vertical Stripe |
Display Area | 304.128(H)×228.096(V) mm | Surface | Antiglare (Haze 25%), Hard coating (3H) |
Outline Size | 326.5(H)×253.5(V) ×10(D) mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
Brightness | 350nit or customized | Display Mode | ADS, Normally Black, Transmissive |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Response Time | 30(Tr/Td) |
Display Colors | 16.7M 72% NTSC | Lamp Type | WLED [12S4P] , 50K hours , With LED Driver |
Frequency | 60Hz | Input Voltage | 3.3V (Typ.) |
Weight | 930g (Max.) | Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
1.Branded LCD panels with perfect image quality and wide viewing angles;
2.Built with industrial-grade components for a reliable 24/7 continuously operation;
3.LED backlight, brightness up to 1000 nits;
4.With light sensor for auto-dimming, to save energy and extend backlight life span;
5.Customization solution available
