Shenzhen Risingstar Outdoor High Light LCD Co., Lt
Min. Order:1 Piece/Pieces
Brand: Risinglcd
Productivity: 250K
Place of Origin: SHEN ZHEN
Certificate: CE/ROSH/UL/ISO9001
| RISINGSTAR | Panel Model | RS173ENT-NE10 |
| 17.3" | Panel Type | a-Si TFT-LCD , LCM |
| 1920(RGB)×1080 (FHD) 127PPI | Pixel Format | RGB Vertical Stripe |
| 381.888 × 214.812 (H×V) | Treatment | Glare (Haze 0%), Hard coating (3H) |
| 403×240×13mm (H×V×D) | Contrast Ratio | 600 : 1 (Typ.) (TM) |
| 1000nit or customized | Display Mode | TN, Normally White, Transmissive |
| 80/80/60/80 (Typ.)(CR≥10) | Response Time | 37/3 (Typ.)(Tr/Td) ms |
| 16.7M 72% NTSC | Lamp Type | WLED , 50K hours , With LED Driver |
| 1.08Kgs (Typ.) | Frequency | 60Hz |
| LVDS (2 ch, 8-bit) , 30 pins Connector | Input Voltage | 3.3 V (Typ.) |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: 0 ~ 70 °C | ||
Risingstar industrial display adopts sturdy metal frame, flat panel LCD Panel design, compact and durable, with the advantages of shock resistance, anti-interference, heat dissipation, etc., and meets the needs of embedded or external installation. Widely used in industrial display, medical display, commercial Lcd Display, financial equipment, self-service terminals, etc.
Industrial high-definition LCD display, 1920x1080 full HD resolution, clear and natural images; at the same time, it has low power consumption, long-term running ability, and can adapt to almost all harsh environments.
Applications
Mainly used in closed-circuit monitoring systems, video, PC operating systems, vehicle navigation systems and other supporting displays, and can also be used in industrial automation, medical machinery and equipment, electric power, petrochemical, marine and military navigation systems. ATM and instrument display systems.
Engineered Solutions
With the development of display technology, Risingstar continues to develop solutions to meet the diverse needs of the display market. Whether your application is a terminal, CRT replacement, HMI, POS, public information display or Digital Signage, this is an easy all-in-one solution for you. Easy to integrate, we combine performance and quality with versatile open frame chassis mountable products. Choose from a variety of optional touchscreens, protective glass, films or privacy shields. Risingstar custom designs and manufactures for OEMs, offering custom enclosures, special power requirements and custom warranty and service packages.
Hot Tags: 17.3 inch 1200nit outdoor advertising screen, China, factory, cheap, price, customized, quotation, window facing LCD, LCD screen For Outdoor, Sulight Lcd Screen, 1000 Nits LCD Screen, Sunlight Readable Lcd Display, high bright lcd panel 49 inch, panel for Outdoor TV
18.5 Inch 1200nit Outdoor Lcd Screen
17＂1500nit Outdoor Touch Screen
