75 Inches 2k High brightness LCD
75 Inches 2k High brightness LCD
75 Inches 2k High brightness LCD
75 Inches 2k High brightness LCD
75 Inches 2k High brightness LCD

75 Inches 2k High brightness LCD

Payment Type:T/T,L/C,D/P,D/A,Paypal

Incoterm:FOB,CFR,CIF,EXW

Min. Order:1 Piece/Pieces

Product Description
Product Attributes

Size75-inches

Brightness1500-nits

Supply Ability & Additional Information

Payment TypeT/T,L/C,D/P,D/A,Paypal

IncotermFOB,CFR,CIF,EXW

Packaging & Delivery
Selling Units:
Piece/Pieces
Product Introduction:
Product Introduction

Brand of panel: Rui Gao Liang

Panel model: RS750ENT-N20

Panel size: 75"

Panel type: a-Si TFT-LCD, liquid crystal module

Number of pixels: 1920(RGB)×1080, FHD

Pixel Layout: RGB Vertical Strip

Display area: 1595.52(W)×897.48(H) mm

Opening size: 1606.0(W)×908.0(H) mm

Appearance size: 1666(W)×968(H) mm

Surface treatment: Haze 2%, hard coating 3 h, reflectivity 2.0% (Max.)

Panel brightness:500-5000 cd/m2

Contrast: 1200:1 (Typ.) (Transmission)

Visual angle: 89/89/89/89 (Min.)(CR≥10)

Operating mode: S-IPS, normally black display, transmissive

Perfect angle: Full Perspective

Reaction time: 12 (Typ.)(G to G) ms

Display color: 16.7M, 72% (CIE1931)

Lamp type: WLED, 60K hours, with LED driver

Operating frequency: 240Hz+240Hz (60Hz input)

Touch Screen: No Touch

Weight: 37.0Kgs (Typ.)

Signal interface: LVDS (2 ch, 10-bit), 63 pins, terminal

Drive screen voltage: 12.0V (Typ.)

Working environment ":working temperature: 0 ~ 50 °C;  Storage temperature:-20 ~ 60 c
