Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch
Outdoor LCD Display Screen 86inch

Outdoor LCD Display Screen 86inch

Min. Order:1 Piece/Pieces

Product Description
Product Attributes

Model No.RS860EQL-GD40

Packaging & Delivery
Selling Units:
Piece/Pieces
Product Introduction:
Product Introduction

       86inch high bright  Outdoor Lcd  module using RisingStar's original industrial-grade LCD Panel, long-term sunlight without blackening;

  1. High and low temperature resistance -30 to 110 degrees;

  2. Aluminum alloy structure, better heat dissipation, 3 times better than the conductivity of the electrolytic plate;

  3. The backlight supports automatic dimming, knob dimming, PWM dimming;

  4. Outdoor special optical materials, with a temperature resistance of 120 degrees Celsius;

  5. Direct backlight design, higher reliability.



  u=697523073,2845787108&fm=26&gp=0












Size
 86inch
Panel item
RS860EQL-GD40
Panel type
a-Si TFT-LCD
Display mode
 IPS,Normally black,transmissive display
Pixels
3840*2160
brightness
4000cd/m2
Constrast Ratio
1400:1
View angle
89/89/89/89 (Min)
View area
1897*1068mm(H*V)
Dispaly area
1895.04*1065.96mm(H*V)
Outline Size
1930*1111*75.5mm(H*V*D)
Working freqyency
60Hz
Working temperature
-20- +70℃
Storage Temperature
-20 - +70℃
Display ratio
16:9
Display color
16.7m/1.7B
Surface Treatment
Haze 3%,Hard coating(2H)
Weight
40kgs
