Shenzhen Risingstar Outdoor High Light LCD Co., Lt
Brand: RisingSTAR
Productivity: 180K
Certificate: CE/ROSH/ISO9001
LD860EQD-FJM1, 86-inch large semi-Outdoor Lcd module, equipped with WLED backlight, including LED driver backlight drive, its display resolution is 3840(RGB)×2160 (UHD), pixels are arranged in RGB vertical stripes.
The LCD panels use a WLED side-entry light source with a service life of 30K hours. Due to its 120Hz, white LED backlight, including LED driver, 8/10 bit gray level optional, surface fog surface and other features, recommended for Digital Signage, electronic whiteboard.
Q:what can you buy from us?
A：semi-outdoor LCD, full Outdoor Highlight Screen, Ultrathin Highlight LCD,Outdoor splicing highlight LCD,Industrial Highlight TFT-LCD, transparent LCD and display frame, double-sided LCD, high-light double-sided LCD and other high-end LCD Panel.
Q:How can i find the right product?
A：Please send us your requirements, we will recommend our standard products, if it's not fit, we will do the necessary adjustment & customization.
Q：What are our advantages?
A：Low price high quality products, timely tracking information
| brand | RisingStar Display | Model name | LD860EQD-FJM1 |
| size | 86 inch | Screen type | a-Si TFT-LCD,Lcd Module |
| resolution ratio | 3840(RGB)×2160[UHD] | Pixel configuration | RGB vertical bar |
| Display Area | 1895.04×1065.96 mm (H×V) | Surface treatment | Fog surface(Haze 3%)，Hard coating (2H) |
| Visual size | 1897.0×1068.0 mm (H×V) | Contrast Ratio | 1200:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1922.2 ×1093.2×43.3(H×V×D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Backlight type | WLED, 30K hours, including LED driver |
| Signal interface | 97 pins V-by-One 16 lane ,erminal | | |
| work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C | | |
