55 Inches High Brightness LCD For Bus Stop

55 inches High Brightness Lcd for bus stop

The electronic station board will adopt a new generation of application system which combines global positioning and navigation technology (GPS), advanced communication mode, geographic information system technology (GIS-T), advanced video transmission technology and intelligent sensor.

Make full use of the bus intelligent scheduling management system of the bus GPS arrival data, through technical docking, establish the bus arrival forecast system. After the completion of the project, the system will cover most of the bus stops and release the real-time arrival information of all the buses passing through the line, which can provide real-time and accurate vehicle arrival forecast for waiting passengers. In addition, the project is equipped with multimedia video playback, real-time video monitoring, passenger feedback and suggestions, public information release services and other functions.

Manufacturer: risingstarlcd model: rs550ent-n25

Diagonal size 55 inch type a-Si TFT-LCD, Lcd Module

Resolution 3840 (RGB) × 2160 UHD 80ppi pixel arrangement RGB vertical stripe

Display area 1209.6 (horizontal) × 680.4 (vertical) mm, appearance size 1233.4 (horizontal) × 706.8 (vertical) × 29.9 (thick) mm

Open area 1214.6 (transverse) × 685.4 mm, haze 28%, hard coating 2H

Display brightness 2500 CD / M ² ( Typ.) contrast 1100:1 (typ.) (transmission)

Recommended view full view response time 8 (typ.) (g to g) MS

Visual angle 89 / 89 / 89 (min.) (CR ≥ 10) left / right / up / down display mode IPS, black display, transmission mode

Support color 1.07b, 70% NTSC light source type WLED, 50K hours, no drive

Weight 13.9/14.4kgs (typ. / max.) applied product digital label

Frame rate 60Hz

Interface type 51 pins v-by-one 8 lane, terminal

Voltage supply 12.0V (typ.)

Working temperature of application environment: 0 ~ 50 ° C; Storage temperature: - 20 ~ 60 ° C
