43 / 55 Inch Battery Lcd Digital Signal

2025-08-01

43 / 55 inch battery digital signal, this is a rechargeable product, lithium battery, 12 hour endurance, high temperature resistant LCD Panel, charged quantity display, rubber pulley

Manufacturer RisingStar display model ld430eue-fhb1

Diagonal size 43 inch type a-Si TFT-LCD, Lcd Module

Resolution 1920 (RGB) × 1080 FHD 51ppi pixel arrangement RGB vertical stripe

Display area 941.184 (horizontal) × 529.416 (vertical) mm, appearance size 963.6 (horizontal) × 567.9 (vertical) × 29.6 (thick) mm

Opening area 945.8 (transverse) × 534.02 (vertical) mm, haze 1%, hard coating (3H)

Display brightness 450 CD / M ² ( Typ.) contrast 1100:1 (typ.) (transmission)

Recommended view full view response time 12 (typ.) (TR + TD) MS

Visual angle 89 / 89 / 89 (min.) (CR ≥ 10) left / right / up / down display mode S-IPS, constant black display, transmission type

Weight 7.50kgs (typ.) applied product digital label

Frame rate 60Hz touch technology no touch

Interface type 51 pins LVDS (2 CH, 8-bit), terminal

Voltage supply 12.0V (typ.)

Working temperature of application environment: 0 ~ 50 ℃ ° C ; Storage temperature: - 20 ~ 60 ° C
