24 Inch 700/1000/1500 Nits LCD Display

24 inch 700/1000/1500 nits Lcd Display

The 24 inch outdoor high-brightness LCD screen is readable by sunlight and will not be blackened by direct sunlight. The price is very good.The backlight comes with a brightness regulator, which supports manual brightness adjustment and PWM brightness adjustment.

Panel brand: (risingstarlcd) Panel model: RS240ENT-N10

Diagonal size 24.0 inch type a-Si TFT-LCD, Lcd Module

Resolution: 1920(RGB)×1080 FHD 91PPI; Pixel arrangement: RGB vertical strip;

Display area: 531.36 (horizontal) × 298.89 (vertical) mm; appearance size: 556 (horizontal) × 323.2 (vertical) × 17 (thickness) mm;

Opening area; 535.36(horizontal)×302.89(vertical) mm; matte surface treatment: Hard coating (3H);

Display brightness: 1000/1500 cd/m² (Typ.); Contrast: 5000:1 (Typ.) (transmission);

Recommended viewing angle: full viewing angle; response time: 16/9 (Typ.)(Tr/Td) ms;

Viewing angle: 89/89/89/89 (Typ.)(CR≥10) left/right/up/down display mode AMVA3, normally black display, transmissive;

Support color: 16.7M, 72% NTSC; light source type: WLED; [10S7P], 50K hours, including LED driver;

Weight: 2.30Kgs (Typ.) applied product industry; frame frequency: 60Hz;

Interface type 30 pins LVDS (2 ch, 8-bit), connector

Voltage supply 5.0V (Typ.);

Application environment working temperature: -20 ~ 70 °C; storage temperature: -30 ~ 80 °C;

Place of Origin: Shanghai, China.
